摘要
本文从小型伸缩臂式叉装车稳定性校核入手，梳理载荷计算和倾覆轴线的确定，深入浅出地讨论了叉装车在静稳定性校核和作业稳定性校核两种方式下的稳定性计算方法，分析计算方法全面有效准确，提高了叉装车操作的稳定性，并且有利于生产现场的安全作业。
伸缩臂式叉装车属于具有一定起重能力的运输机械，它是由一个类似装载车的四轮驱动轮式底盘和一套能左右及上下自由伸展的伸缩臂工作装置组成的。该类型叉装车主要用于车站、工地、港口、大型农场和工厂等地，进行成件包装货物的搬运和装卸，其货叉部分是一个可以快速更换的装置，根据工作需要，可配备其它工作属具，可实现前进、后退、原地转向等操作，使用灵活，操作自如。
近几年，随着大型农场、超市、港口建设的加速，对货物搬运的需要，对叉装车的需求激增，而满足其条件的兼备叉车功能和装载机的越野性能同时，又具有一定的起重能力的伸缩臂式叉装车也愈来愈受到人们的喜爱，目前国内还未投产此类产品。
本文就是针对麦力 MANITOU MT-X 1030 ST型伸缩臂叉装车进行静态和动态稳定性分析。希望本文所做的研究对伸缩臂叉装车的整机设计和性能研究具有一定的参考价值。

关键词：伸缩臂叉装车；稳定性；动态，静态；

Abstract
This article from the small telescopic jib fork truck loading stability check of carding load calculation and determination of the overturning axis, a simple discussion about the fork truck loading in the static stability and operation stability respectively under the two ways of stability calculation, analysis and calculation method of full and accurate, and improve the stability of fork truck loading operation, is advantageous to the production site safety operation.
Telescopic boom forklift truck is a kind of transport machinery with certain lifting capacity. It is composed of a four-wheel drive wheel chassis similar to the loading truck and a set of telescopic boom working device that can freely extend from left to right and up and down. This type of fork truck loading is mainly used in the station, construction, ports, large farms and factories into the packing of goods handling, loading and unloading, the pallet fork part is a device that can quickly change, as required by work, can work with other fittings, can realize forward, backward, spin, such as operation, flexible use, operate freely. [资料来源：www.doc163.com]
In recent years, with the acceleration of large farms, supermarkets, port construction, the need for goods transportation, a surge in demand for fork truck loading, and meet their conditions have both forklift and loader function of cross-country performance at the same time, also has certain type telescopic crane lifting capacity of fork truck loading is also more and more popular with people, has not been put into production at home and abroad, this kind of product.
In this paper, the static and dynamic stability analysis of the miley MANITOU mt-x 1030 ST telescopic arm forklift is conducted. It is hoped that the research in this paper has certain reference value to the design and performance research of the telescopic arm forklift.
Key Words：Telescopic boom forklift truck；stability；machinery
