摘要
轴是重要的机器零件之一，它的设计主要包括结构设计及强度，刚度校核两部分。轴的设计是十分繁琐的过程，特别是再按疲劳强度进行精度校核时，需要检索大量的图表，作大量的运算。通常这一过程由有一定经验的工程技术人员进行。由于计算过程繁杂，所以一旦校核合格一般不重新进行，即使在安全系数余很大的情况下也是如此。
随着计算机技术的发展，计算机正在越来越广泛地应用于机械设计的各个方面以及各种各样的机械设计中，它在提高机械设计的质量和转化为实际制造的效率方面，发挥着重要作用。计算机辅助设计便是伴随着计算机技术的发展而出现，并广泛应用于多种学科的一种方法。计算机辅助设计又被称作“CAD”，是由计算机帮助设计人员完成机械设计中的计算、制图、模拟等工作，并在不断修改和反复验证的基础上，输出满意的设计结果和最后的产品图纸的一门技术。
设计过程编成计算机程序，大量的检索，计算及绘图任务由计算机来完成，这不仅能提高设计速度，改善设计质量，还能把有经验的设计人员从繁琐劳动中解放出来，从事更有意义和研究性的工作。 [资料来源：Doc163.com]
关键词：轴  计算机辅助设计  编程

Axis computer-aided design
Abstract
Axis is an important part of the machine, its design includes structural design and strength, rigidity checking two parts. Axis design is a very tedious process, especially the fatigue strength and then checking the accuracy, you need to retrieve a large number of charts, for a large number of operations. Usually this process by having some experience engineering and technical personnel. Complex process of calculation, so once the check is generally not re-pass, even in the case of large safety factor than the well.
With the development of computer technology, computers are becoming more widely used in all aspects of mechanical design and a variety of mechanical design, mechanical design it to improve the quality and efficiency of manufacturing into practical aspects play an important effect. Computer-aided design is accompanied by the emergence of computer technology, and is widely used in a variety of disciplines in a way. Computer-aided design, also known as "CAD", was completed by the computer to help the designer in the calculation of mechanical design, drafting, simulation, etc., and constantly modify and repeated verification, based on the output of a satisfactory outcome and final product design drawing a technical.

    Compiled computer program design process, a large number of retrieval, calculation and drawing tasks done by the computer, which not only can improve the design speed, improve design quality, but also the experienced designers freed from tedious labor, engaged in more meaningful and research work.
Keywords: Axis    Computer Aided Design    Program
  [资料来源：http://Doc163.com]

摘要    I
Abstract    II
第一章 绪论    1 [资料来源：http://www.doc163.com]
1.1 引言    1
1.2 文献综述    1
1.3 论文主要工作    3
第二章 轴的计算原理    4
2.1 引言    4
2.2初算最小轴径    4
2.3拟定轴的装配方案    5
2.4确定轴的各段直径和长度    6
2.5校核轴的应力    7
2.6校核轴的疲劳强度    9
第三章 轴计算机辅助计算程序设计    12
3.1 引言    12
3.2 VB简介    12
3.3 程序设计流程    13
3.4程序设计    17
3.5程序调试    21
第四章 轴计算机辅助计算实例    22
4.1引言    22
4.2 轴计算机辅助计算实例    22
4.3 图形设计    30
第五章 全文总结    31
5.1 总结    31
5.2 展望    31
参考文献    32

[资料来源：http://Doc163.com]

致谢    34
